Perforated screen Product Introduction
Perforated screen is a mesh product made of high quality sheet metal in CNC punching machine according to customized die continuous blanking.
Perforated screen has round hole, oval hole, round hole, square hole, square hole, triangle hole, five-pointed star hole, hexagonal hole, figure eight hole, cross hole, square hole, zigzag hole, herringbone hole, H hole, diamond hole, fish scale hole, nail hole, bridge hole, louver hole, round drum hole, crocodile mouth hole and other holes. Aperture size, hole spacing, arrangement, etc., can be customized production.
Perforated screen material has a lot of conventional material have iron Perforated screen, Perforated screen aluminum, stainless steel Perforated screen, thickness and surface size can be customized according to requirements for processing.
Perforated screen Specification Description
Perforated screen There are many specifications, material, thickness, size, pass, aperture, spacing, etc. can be customized according to the requirements of production.
Perforated screen Material: iron plate (cold rolled plate, hot rolled plate, galvanized plate, manganese steel plate, low carbon steel plate, Q235);
Aluminum plate (1 series aluminum plate such as 1050, 1060, 1070, 1100, etc., 3 series aluminum plate such as 3003, 3004, 3104, etc., 5 series aluminum plate such as 5005, 5052, 5083, etc.);
Stainless steel plate (201 stainless steel, 304 stainless steel, 316 stainless steel, 316L stainless steel, 409 stainless steel, 430 stainless steel, etc.).
Perforated screen thickness: Perforated screen The thickness can be customized from 0.3mm-20mm, but according to the principle of the smallest hole, that is, the aperture size shall not be less than the thickness of the plate.
Perforated screen size: Perforated screen The conventional size is 1 m *2 m, 1.22 m *2.44 m, 1.25 m *2.5 m, 1 m *20 m, 1.2 m *20 m and so on, special size can be customized according to requirements.
Perforated screen Pass type: Perforated screen hole type has round hole, oval hole, round hole, square hole, square hole, triangle hole, five-pointed star hole, hexagonal hole, figure eight hole, cross hole, square hole, zigzag hole, zigzag hole, diamond hole, fish scale hole, nail hole, bridge hole, louver hole, round drum hole, crocodile mouth hole and other hole series, special hole can be made to order drawing sample processing.
Perforated screen aperture: Perforated screen aperture from 0.5mm-300mm can be customized production, conventional round hole aperture from 1mm-20mm, some thickness of the spot sale.
Perforated screen spacing: Perforated screen hole spacing can be customized according to requirements, under normal circumstances, the spacing from hole edge to hole edge is greater than 1.5 times the thickness of the plate can be.
Perforated screen Price introduction
Perforated screen The price is quoted according to specifications and models, the price of Perforated screen is different for different specifications and models. Users who want to know the price of Perforated screen can send us an email and tell us the specifications and models you need, purchase quantity, receiving address, etc., we will offer you a precise price according to your requirements.
